Spectral:ONfly CF 8

Refurbished bike in M
-13%

$5,199

Original price ~~$5,999~~

You save $800

Financing available for this product

An epic trail-capable eMTB with a compact motor, wrapped up in an affordable ‘ready for anything’ package.

Weight: 41.67 lbs
Material: Carbon (CF)

Colour: Barely Olive

Members only product.

Frame Size: M

Select your model

Ships within 1-3 business days

Only 1 left in stock

Attention: It is not always possible to show all signs of wear. You should expect other scratches, paint damage and/or signs of use. Pricing is adjusted according to the wear class (light, medium or heavy signs of use).

Members only product.

$5,199

Original price ~~$5,999~~

You save $800

Financing available for this product

Ships within 1-3 business days

Only 1 left in stock

Additional information

Current delivery times information. Read more

Financing with PayPal

Financing with Klarna

Financing with Affirm Financing

Financing available for this product
Get ready-to-ride Delivery

Ready to ride delivery with velofix DIRECT

With velofix DIRECT, you can schedule delivery directly to your home or office. A professional technician can deliver, build, and dial in your new bike.

Collect & Ride

Nervous about building your new bike? Have your bike sent directly to your local bike shop to be assembled by an expert. Collect your bike at a time that suits you.
How to choose Collect & Ride
6 Year Warranty on all Canyon-manufactured parts (frame, road bike fork, cockpit, etc.)
Learn More

Ships within 1-3 business days

Wear level

Slight signs of use

Bikes in this category may have the odd scratch, chipped paintwork or colour deviations. The cassette and chain will have been used but display no obvious signs of wear. Please note, this bike is a final sale and may not be returned.

These images show model #0001117715

Highlights Spectral:ONfly CF 8

Trail through and through

More control. More fun.

We’ve equipped each Spectral:ONfly with K.I.S.—an ingenious spring mechanism housed inside the top tube that helps center your steering. End result? You experience more control on sketchy descents, more grip when its loose, and more fun in rough, off-camber conditions.

Fine tune your handling

You can custom tune how K.I.S. feels—with a simple twist of an allen wrench—to suit your own ride style and conditions. What’s more, K.I.S. is totally maintenance-free, protected from damage, and has a lifetime warranty. Don’t fancy K.I.S.? Each bike comes with an easy to install blanking plate that covers the adjuster slot.

What is :ONfly?

:ONfly is our line of innovative, lightweight e-bikes that range from e-MTB to e-gravel machines. Featuring sleek, compact motors and batteries, our :ONfly models hit the elusive sweetspot between traditional bikes and full power e-bikes.

CLLCTV approved

“Wait, this is an e-bike? There were multiple moments on the trail when I forgot I was riding an E-MTB. The bike feels super playful and lightweight. It’s nice to just pedal and not worry about how hard you are working.” — Samantha Soriano, Professional Freeride MTB athlete.

Components

Frame

Frame
- Canyon Spectral:ONfly CF
- Axle dimension 12x148 mm
- Material Carbon (CF)
- Weight 2,700 g
Rear Shock
- Rockshox Deluxe Select +
Suspension Fork
- RockShox Lyrik
- Axle dimension 15x110 mm
- Stanchion Diameter 35 mm
- Travel 160 mm
- Fork steer tube diameter 1 1/8" - 1,5"
- Offset 44 mm
- Volume Spacer Oe 0/5
- Weight 2,340 g
Seatpost Clamp
- Canyon GP0446-01

Drivetrain

Motor
- TQ HPR 50 Motor
Battery
- TQ HPR Battery
Rear Derailleur
- Shimano Deore M6100, 12-Speed
- Cage length long
- Weight 356 g
Chainguard
- Canyon GP0480-01 slim
Shift Lever
- Shimano Deore M6100, 12-Speed
- Weight 136 g
Cassette
- Shimano Deore M6100
- Number of sprockets 12
- Range 10-51
Crank
- FSA CK-745/IS Armset
Chainring
- Chainring FSA W0190
Chain
- Shimano Deore M6100

Brakes

Disc Brake
- SRAM Code R
- Number of pistons 4
Disc Brake
- SRAM Code R
- Number of pistons 4
Brake Rotor
- SRAM Centerline Rounded
- Size 200 mm
- Weight 228 g

Wheels

Front Wheel
- Sunringle 329 Trail Expert
- Axle dimension 15x110 mm
- Rotor mount Center Lock
- Rim material Aluminium
- Weight 940 g
Rear Wheel
- Sunringle 327 Trail Expert
- Axle dimension 15x110 mm
- Rotor mount Center Lock
- Rim material Aluminium
- Weight 1,050 g
Tyre
- Maxxis Minion DHR II Exo
- Width 2,4"
- Weight 1,035 g
Tyre
- Maxxis Minion DHR II Exo+
- Width 2.4"
- Weight 1,000 g
Thru Axle
- Canyon Quixle Through Axle QR 148x12
- Axle dimension 12x148 mm

Cockpit

Stem
- Canyon:ON ST0031 Stem
- Canyon E-MTB stem.
- Length 45 mm
- Fork steer tube diameter 1 1/8"
- Clamping diameter 35,0 mm
- Material Aluminium (AL)
Handlebar
- Canyon:ON HB0057 Riser bar
- Canyon-developed E-MTB handlebar for top control levels on the trail.
- Clamping diameter 35,0 mm
- Rise 30 mm
Grips
- Canyon Lock-On

Seat

Saddle
- Fizik Terra Aidon X5
- Gender Unisex
- Weight 251 g
Seatpost
- Canyon SP0070-01
- Air cartridge. Cable actuated.
- Travel Dependent on frame size (see component geometry table.)
- Seatpost diameter 34,9 mm
- Material Aluminium (AL)
- Weight 654 g

Light

Lights
- Reflector Set

Accessories

Pedals
- VP-536 flat pedals
Manuals and Accessories
- Canyon Organza Bag
Manuals and Accessories
- Wrench Tool 15mm
Manuals and Accessories
- Canyon Assembly Paste
Manuals and Accessories
- Canyon Torque Wrench
Manuals and Accessories
- Declaration of confirmity M095
Manuals and Accessories
- QSG M095
Manuals and Accessories
- Pedelec Manual 005-V04
Manuals and Accessories
- Canyon Smallbox
Manuals and Accessories
- Canyon Shock Pump 300 Psi

Content is loading

Geometry & dimensions

Basic geometry

Detailed geometry table

Body Height in cm	≤ 175	175 - 183	183 - 192	≥ 192
Seat Height in mm (a)	635 - 785	680 - 830	710 - 860	750 - 900
Seat Tube Length in mm (b)	400	415	445	455
Top Tube Length in mm (c)	594	621	648	675
Head Tube Length in mm (d)	105	115	125	135
Head Tube Angle (e)	64°	64°	64°	64°
Seat Tube Angle (f)	76,5°	76,5°	76,5°	76,5°
Chainstay Length in mm (g)	440	440	440	440
Wheel Base in mm (h)	1.221	1.251	1.280	1.309
Stack in mm (i)	620	629	638	647
Reach in mm (j)	445	470	495	520
Stand-over Height in mm (k)	734	739	743	747
Bottom Bracket Offset in mm (l)	31	31	31	31

Component geometry

Detailed geometry table

Spacer in mm	15	15	15	15
Stem Length in mm	45	45	45	45
Handlebar Width in mm	760	780	780	780
Crank Length in mm	170,0	170,0	170,0	170,0
Seat Post Diameter in mm	34,9	34,9	34,9	34,9
Dropper post travel in mm	170	200	200	230
Seat Post Length in mm	457	517	517	587
Maximum Seat Post Insertion Depth in mm	270	300	300	340
Minimum Seat Post Insertion Depth in mm	120	150	150	190
Wheel Size	29"/27.5"	29"/27.5"	29"/27.5"	29"/27.5"
Disc Size in mm	200 / 200	200 / 200	200 / 200	200 / 200
Front Fork Travel in mm	160	160	160	160
Rear Suspension Travel in mm	150	150	150	150
Battery capacity	360 Wh	360 Wh	360 Wh	360 Wh
Fitting Length	210X55	210X55	210X55	210X55
